Maximize Power and Performance with GDP Portals
Take your Honda Rancher to the next level with SuperATVs 6 Portal Gear Lift. You get a lift and a gear reduction in one package. So choose between a 30% or 45% gear reduction to boost your torque for the way you ride. Plus; youll get extra ground clearance and room to run massive tires. If you want the ultimate upgrade; our GDP Portals are the way to go.

Get the Torque You Need
With a 30% or 45% gear reduction; youll get more torque and better acceleration. A 45% reduction gives you maximum power to handle deep mud; big hills; and and massive tires. If you want a balance between speed and torque; the 30% reduction is the perfect choice.

Protect Your Drivetrain
All that extra power can wear down your drivetrain—but GDP Portals protect it. The gear reduction is built into the hub; which means your axles; differential; and transmission wear less. Our Honda Rancher also portals keep your stock suspension geometry; so your axles run cooler and last longer.

Built Tough for Hard Rides
When you're ripping through trails; you need portals that wont quit. Our cast and 6061 billet aluminum housings are designed for the roughest terrain. Plus; theyre reinforced with advanced steel backing plates for unmatched strength.

• Our housings are reinforced for gear retention and optimized for oil flow
• Advanced steel alloy backing plates are stronger than chromoly
• Enhance with Portal Blood—gear oil formulated for GDP Portals
• There are no gimmicks and no vents because vents do more harm than good—we know because we tested them

Advanced Gaskets; Seals; and Bearings
Our portals use:

• Advanced gaskets and O-rings with excellent oil resistance and low deterioration rates
• A sealed input gear and double-lipped output seal
• 100% sealing coverage throughout so you can forget about oil leaks
• Double-angular contact output bearings to prevent premature wear
• Roller idler and drive bearings to maintain perfect gear meshing

Top-Rated Customer Service
Not sure which setup is right for you? Our expert team is ready to help. Call us today; and well make sure you get the perfect set of portals for your Rancher.

6 Portal Gear Lift Includes:

• (4) Assembled portal hub boxes complete with 9310 gears; seals; output shaft; gaskets; and thrust bearings
• (4) Universal hubs and precision-ground stainless steel slotted rotors with lugs
• (4) Specialized steel alloy backing plates
• (2) Steel caliper mounting plates
• (2) Caliper mounting plate shims
• Extended brake lines
• All required hardware; including recessed castle nut socket

Honda Rancher Max Tire Size Recommendations
Tire Size	Required Suspension Setup with 6 Portals
28	Stock
If you need help figuring out which gear reduction is right for you; check out our portal gear reduction calculator.		Max tire sizes are measured at full compression and full turn. The given tires sizes are the largest we fit without rubbing. With minor trimming or a small amount of rub; larger tire sizes can be used.

Patent # 11;299;042

Patent # 11;318;787

• Honda Rancher 420 : 2014+

NOTE: Only compatible on machines with IRS (Independent Rear Suspension)

Wheel Requirements

• 18 or larger wheel required
• 20 and larger wheels cannot exceed 5 backspacing
• Wheels need to have a center hole of at least 3.25 (82.55mm) or require a 1 wheel spacer
